How to operate the control panel of kuike automatic computer knitting machine?

"Needle head left limit" and "Hand head right limit" manually move the machine head to the left and right, so that the machine head limit iron piece is close to the left and right limit induction probes, and maintain a certain distance of the number of needles (probe indicator light off, the signal detection status is "0") to stop moving the nose, press the F1 key to write the currently displayed needle value (this value is a negative integer).

"Synchronous belt pitch correction": Set the timing belt pitch (pulse value within the total number of needles) when the machine head is knitting. Press the Enter key, the synchronous belt pitch correction screen will pop up. Move the machine head to the left of the needle bed, align the left side of the machine head with the first needle of the needle bed, and press the number "1" to input the left pulse value. Move the machine head to the right side of the needle bed, align the left outer side of the machine head with the last stitch of the needle bed, press the number "2", input the right pulse value, then press the number "3", and press the Enter key to end.

"Left System Yarn Feeder Right Row Zero Position" "Left System Yarn Feeder Left Row Zero Position": Manually align the center of the thread outlet of a yarn feeder (generally choose No. 1) to the first needle on the left side of the fixed needle plate At the center, then move the machine head by hand, align the right and left sides of the "1" shuttle changing electromagnet core of the left system with the right and left sides of the upper displacement cutout of the shuttle box, press the F1 key to write the current needle value, "Compensation for the left and right rows of the needle selector" Press the Enter key to operate, and set the compensation value and range of the left and right rows of the needle selector; -79—+79.

"Electromagnet High Voltage" set the high voltage value (sensitivity) of the action electromagnet and press the Enter key to operate, the range is 1-10.

"Needle selector high pressure and low pressure" Set the needle selector high pressure and low pressure value. (Sensitivity) range; 2-5.

"Density motor reset and working speed" Set the density motor to zero reset and working speed, press the Enter key to operate, the range is 1-10.

"Machine head move out enable" When the head move out enable is turned on. It is mainly used to correct the setting of the relationship between the stop point of the sand nozzle and the knitting speed of the machine head. When the relationship setting is established, the machine head is turned off and enabled, and the system automatically calculates the drop and lift points of the sand nozzle according to the corrected values during debugging.

Knitting Machine: A machine that knits "knitted fabrics". In 1589 the English priest William Lee invented the first hand knitting machine. In the 1870s, with the invention of the electric motor, the hand knitting machine was replaced by the high-speed electric knitting machine and the fully automatic knitting machine.
